MBR10100
Document number: DS31412 Rev. 11 - 2
2 of 4
www.diodes.com
April 2011
? Diodes Incorporated
MBR10100CTP
Maximum Ratings (Per Leg)
@TA
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
VRRM
VRWM
VRM
100 V
Average Rectified Output Current
(Per Leg)
IO
5
A
(Total)
10
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
IFSM
100 A
Isolation Voltage
From Terminal Heatsink t = 1 min.
VAC
2000 V
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Typical Thermal Resistance Junction to Case
RθJC
3
°C/W
Operating and Storage Temperature Range
TJ, TSTG
-65 to +175 oC
Electrical Characteristics (Per Leg)
@TA
= 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop
VF
- 0.79 0.85
- 0.65 0.75 V
IF
= 5A, T
J
= 25oC
IF
= 5A, T
J
= 125oC
Leakage Current (Note 3)
IR
- - 0.1
- - 15 mA
VR
= 100V, T
J
= 25oC
VR
= 100V, T
J
= 125oC
Notes: 3. Short duration pulse test used
to minimize self-heating effect.
Fig. 1 Typical Forward Characteristics
0.01
0 200 400 600 800 1,000 1,200 1,400
0.1
1
10
100
V , INSTANTANEOUS FORWARD VOLTAGE (mV)F
I , INSTANTANEOUS FORWARD CURRENT (A)
F
T = 25°CA
T = -55°CA
T = 85°CA
T = 125°CA
T = 150°CA
Fig. 2 Typical Reverse Characteristics
V , INSTANTANEOUS REVERSE VOLTAGE (V)R
I , INSTANTANEOUS REVERSE CURRENT (μA)
R
0.01
0.1
1
10
100
1,000
10,000
020406080100
T = 25°CA
T = 85°CA
T = 125°CA
T = 150°CA
